Product Catalog

ANALOG CCTV CAMERA

Model No.︰-
Brand Name︰-
Country of Origin︰China
Unit Price︰US $ 300 / pcs
Minimum Order︰12000 pcs
Share on:

 Total 19 Related Items
Prev1213141516Next

Product Description



Shenzhen YCX Electronics CO., LTD., top cctv manufacturers in China, is one of the leading CCTV camera manufacturers with over 11 years of experience. YCX now has more than 260 workers, over 50 of which are R & D engineers and international technical support, and owns 5000 square meters plant. YCX company usually invests 10% of annual sales revenue to research and development for product innovation and patented case. YCX mainly provides clients with OEM and ODM Services, such as OEM logo, box, language and customized GUL, API and SDK to enhance customer competitiveness.



HD Analog cameras contain from the traditional Analog CVBS signal 960H 700TVL, 1200TVL into the High definition signal AHD, TVI and CVI technology. CVBS is a "composite video baseband signal." is considered an original analog standard-definition video camera. Which is analog TV lines resolution and not high definition. AHD stands for "Analog HD." AHD technology was adopted by Korean image sensor manufacturers such as Nextchip. TVI is a high definition "transport video interface" and developed by TVI by top one security manufacturer Hikvision. TVI transmits high-definition analog videos over a coaxial cable, which is an HD security camera technology in the United States. CVI is a high definition "composite video interface." was adopted by the famous Chinese manufacturer Dahua. In a later development, AHD, TVI, CVI and CVBS are all combined into the 4 IN 1 Camera that can be switched by DIP or OSD button. Then the customer can use it more flexibly, 4 IN 1 HD camera can directly connect with DVR and control all functions with UTC by coax cable.



How does Analog CCTV Camera work?

The new analog camera is the high definition signal AHD, TVI and CVI technology. Which allows one to record HD resolution video, playback and config the parameters by UTC. The HD 4 IN 1 (AHD/CVI/TVT/CVBS) camera continues to use standard BNC coax cable, DVRs, and can be easily mixed into existing system. The benefits of HD analog are cost-effective, simple installation and easy integration.



What is UTC?

UTC means up to coax. No need to manually use the OSD button to control the camera, DVR by UTC can control and config the camera parameters' directly. It is more convenient.



How to enter to the camera menu ?

In general, the DVR must have the coaxial control feature. Go to the PTZ control window and click the "+ iris -" to call out the camera menu, click +zoom- to zoom in and zoom out.



How far does the video signal transmit?

Over 300 meters long-distance video signal transportation.



What is the camrea working temperature?

Please install this device at the appropriate temperature, -30 - 60 or -22 - 140, keep away from corrosive gas and liquid.



We provide analog and digital cctv camera, mini analog camera, ip to analog converter cctv, analog camera to ip camera converter,etc. We also offer the detail about analog vs ip cctv system   and ip camera vs analog camera ppt.



Payment Terms︰T/T
